EASYTap Through Hole (Type M-6HX) LH
TC-BM 6X1-6HX-ET0-11-A
: 7465279
P
K
M
N
(A25) | (A1) | (A21) | (A3) | (B3) | (B1) | (D1) | |
|---|---|---|---|---|---|---|---|
7465281 | M10x1,5-6HX | M | 10 | 1,5 | 100 | 24 | 3 |
7465282 | M12x1,75-6HX | M | 12 | 1,75 | 110 | 28 | 3 |
7465283 | M14x2-6HX | M | 14 | 2 | 110 | 30 | 3 |
7465284 | M16x2-6HX | M | 16 | 2 | 110 | 32 | 3 |
7465285 | M20x2,5-6HX | M | 20 | 2,5 | 140 | 34 | 3 |
7465286 | M24x3-6HX | M | 24 | 3 | 160 | 38 | 3 |
7465276 | M3x0,5-6HX | M | 3 | 0,5 | 56 | 11 | 3 |
7465277 | M4x0,7-6HX | M | 4 | 0,7 | 63 | 13 | 3 |
7465278 | M5x0,8-6HX | M | 5 | 0,8 | 70 | 16 | 3 |
7465279 | M6x1-6HX | M | 6 | 1 | 80 | 19 | 3 |
7465280 | M8x1,25-6HX | M | 8 | 1,25 | 90 | 22 | 3 |
