EASYTap Blind Hole (Type M-6H+0.1)
TC-CM 6X1-6H+0.1-ET45-11
: 7465359
P
K
M
N
(A25) | (A1) | (A21) | (A3) | (B3) | (B1) | (D1) | |
|---|---|---|---|---|---|---|---|
7465361 | M10x1,5-6H+0.1 | M | 10 | 1,5 | 100 | 12 | 3 |
7465362 | M12x1,75-6H+0.1 | M | 12 | 1,75 | 110 | 14 | 3 |
7465363 | M16x2-6H+0.1 | M | 16 | 2 | 110 | 16 | 3 |
7491485 | M2x0,4-6H+0.1 | M | 2 | 0,4 | 45 | 3,2 | 2 |
7465356 | M3x0,5-6H+0.1 | M | 3 | 0,5 | 56 | 3 | |
7465357 | M4x0,7-6H+0.1 | M | 4 | 0,7 | 63 | 5,6 | 3 |
7465358 | M5x0,8-6H+0.1 | M | 5 | 0,8 | 70 | 6,4 | 3 |
7465359 | M6x1-6H+0.1 | M | 6 | 1 | 80 | 8 | 3 |
7465360 | M8x1,25-6H+0.1 | M | 8 | 1,25 | 90 | 10 | 3 |
