S41

EASYTap Blind Hole (Type UNC-2BX)

TC-CUNC 3/4-10X25,4-ET45-11

: 7465572

Threading shank toleranceBlind hole threadcorresponds with 45° spiral angleChamfer formsThread tolerance

P

K

M

N

85,70 €

85,70 €

(A25)

(A1)

(A21)

(B3)

(B1)

(D1)

7465565

#10-24UNC-2B

UNC

4,826

70

8,5

2

7465566

#12-24UNC-2B

UNC

5,486

80

8,5

2

7465559

#2-56UNC-2B

UNC

2,184

45

3,6

2

7465560

#3-48UNC-2B

UNC

2,515

50

3,6

2

7465561

#4-40UNC-2B

UNC

2,845

56

5,1

2

7465562

#5-40UNC-2B

UNC

3,175

56

5,1

2

7465563

#6-32UNC-2B

UNC

3,505

56

6,4

2

7465564

#8-32UNC-2B

UNC

4,166

63

6,4

2

7465567

1/4-20UNC-2B

UNC

6,35

80

10,2

2

7465570

1/2-13UNC-2B

UNC

12,7

110

15,6

3

7465574

1-8UNC-2B

UNC

25,4

160

31,8

4

7465569

3/8-16UNC-2B

UNC

9,525

100

12,7

3

7465572

3/4-10UNC-2B

UNC

19,05

125

25,4

4

7465568

5/16-18UNC-2B

UNC

7,938

90

11,3

3

7465571

5/8-11UNC-2B

UNC

15,875

110

18,5

3

7465573

7/8-9UNC-2B

UNC

22,225

140

28,2

4
