HPC01 Rougher 33/35/37 UNI (Weldon Shank)
EM-HPC01 U8.0x9/16 3C0.2HB
: 7432439
P
S
K
M
N
(A1) | (B2) | (B5) | (B4) | (C3) | (F22) | (B9) | |
|---|---|---|---|---|---|---|---|
7432436 | 4 | 5 | 54 | 8 | 6 | 3 | 8 |
7432452 | 4 | 8 | 54 | 12 | 6 | 3 | 12 |
7432437 | 5 | 6 | 54 | 10 | 6 | 3 | 10 |
7432453 | 5 | 10 | 54 | 15 | 6 | 3 | 15 |
7432438 | 6 | 7 | 54 | 16 | 6 | 3 | 16 |
7432454 | 6 | 13 | 57 | 21 | 6 | 3 | 21 |
7432439 | 8 | 9 | 58 | 20 | 8 | 3 | 20 |
7432455 | 8 | 19 | 63 | 27 | 8 | 3 | 27 |
7432440 | 10 | 11 | 66 | 24 | 10 | 3 | 24 |
7432456 | 10 | 22 | 72 | 32 | 10 | 3 | 32 |
7432441 | 12 | 12 | 73 | 26 | 12 | 3 | 26 |
7432457 | 12 | 26 | 83 | 38 | 12 | 3 | 38 |
7432442 | 16 | 16 | 82 | 32 | 16 | 3 | 32 |
7432458 | 16 | 32 | 92 | 44 | 16 | 3 | 44 |
7432443 | 20 | 20 | 92 | 40 | 20 | 3 | 40 |
7432459 | 20 | 38 | 104 | 54 | 20 | 3 | 54 |
