EASYTap Blind Hole (Type UNF-2BX)
TC-CUNF #10-32X8,5-ET45-11
: 7465598
P
K
M
N
(A25) | (A1) | (A21) | (B3) | (B1) | (D1) | |
|---|---|---|---|---|---|---|
7465598 | UNF#10x32-2BX | UNF | 4,826 | 70 | 8,5 | 2 |
7465599 | UNF#12x28-2BX | UNF | 5,486 | 80 | 8,5 | 2 |
7465592 | UNF#2x64-2BX | UNF | 2,184 | 45 | 3,6 | 2 |
7465593 | UNF#3x56-2BX | UNF | 2,515 | 50 | 3,6 | 2 |
7465594 | UNF#4x48-2BX | UNF | 2,845 | 56 | 5,1 | 2 |
7465595 | UNF#5x44-2BX | UNF | 3,175 | 56 | 5,1 | 2 |
7465596 | UNF#6x40-2BX | UNF | 3,505 | 56 | 6,4 | 2 |
7465597 | UNF#8x36-2BX | UNF | 4,166 | 63 | 6,4 | 2 |
7465604 | UNF1/2x20-2BX | UNF | 12,7 | 100 | 15,6 | 3 |
7465600 | UNF1/4x28-2BX | UNF | 6,35 | 80 | 10,2 | 2 |
7465609 | UNF1x12-2BX | UNF | 25,4 | 140 | 31,8 | 4 |
7465607 | UNF3/4x16-2BX | UNF | 19,05 | 110 | 25,4 | 4 |
7465602 | UNF3/8x24-2BX | UNF | 9,525 | 90 | 12,7 | 3 |
7465601 | UNF5/16x24-2BX | UNF | 7,938 | 90 | 11,3 | 3 |
7465606 | UNF5/8x18-2BX | UNF | 15,875 | 100 | 18,5 | 3 |
7465603 | UNF7/16x20-2BX | UNF | 11,113 | 100 | 14,5 | 3 |
7465608 | UNF7/8x14-2BX | UNF | 22,225 | 125 | 28,2 | 4 |
7465605 | UNF9/16x18-2BX | UNF | 14,288 | 100 | 16,9 | 3 |
